LS-50 Latching Multi-Point Liquid Level Switch


    The LS-50 has a float and set of stop rings at each switch point that holds the switch "ON" as the liquid level rises.  This ability to hold the switch "ON" helps prevent logic problems in case of mid-cycle power loss.  This product is ideally suited for use with control panel mounted relays.

    Typical applications include controlling low power panel relays, panel lights, low power electronic alarm horns, and programmable logic controllers.  For more information, download the LS-50 Data Sheet.
























Part Number

Wet End Material

Column Length

Base Price 6 = B

Switch Point Adder

LS-50F-0160

PVDF

To 3 Ft.

$594.00

$168.00

LS-50P-0260

PP

To 6 Ft.

$420.00

$102.00

LS-50F-0260

PVDF

To 6 Ft.

$714.00

$168.00

LS-50P-0360

PP

To 9 Ft.

$510.00

$102.00

LS-50F-0360

PVDF

To 9 Ft.

$834.00

$168.00

LS-50P-0460

PP

To 15 Ft.

$642.00

$102.00

LS-50F-0460

PVDF

To 15 Ft.

$1,140.00

$168.00

6 = Number of Swtiches

A = 1 Switch   B = 2 Switches

C = 3 Switches D = 4 Switches

E = 5 Switches F = 6 Switches

G = 7 Switches   H = 8 Switches
