LS-40 Pulsing Multi-Point Liquid Level Switch


    The LS-40 is a multiple switch point level switch.  It contains simple "make and break" switches in almost any configuration that you require.  This makes this level switch the ideal product to use with low power panel mounted control relays.  It's plastic construction makes it more corrosion resistant than stainless steel and more economical.

    Typical applications include controlling low power panel relays, panel lights, low power electronic alarm horns, and programmable logic controllers.  For more information, download the LS-40 Data Sheet.
























Part Number

Wet End Material

Column Length

Base Price 6 = B

Switch Point Adder

LS-40F-0160

PVDF

To 3 Ft.

$480.00

$54.00

LS-40P-0260

PP

To 6 Ft.

$354.00

$54.00

LS-40F-0260

PVDF

To 6 Ft.

$594.00

$54.00

LS-40P-0360

PP

To 9 Ft.

$444.00

$54.00

LS-40F-0360

PVDF

To 9 Ft.

$720.00

$54.00

LS-40P-0460

PP

To 15 Ft.

$582.00

$54.00

LS-40F-0460

PVDF

To 15 Ft.

$1,020.00

$54.00

6 = Number of Swtiches

A = 1 Switch   B = 2 Switches

C = 3 Switches D = 4 Switches

E = 5 Switches F = 6 Switches

G = 7 Switches   H = 8 Switches
