LC-91 Latching Liquid Level Controller with High Alarm

lc91.jpg (16695 bytes)    The LC-91 is a high / low latching liquid level controller ideally suited for automating tank filling and emptying operations.  What makes this unit different then the LC-90 is the inclusion of a high level alarm set point.   It's plastic construction makes it more corrosion resistant than stainless steel and more economical.  The LC-91 contains both fill and empty circuits in one unit.  Use one or both to meet your application.  This unit can control: Pumps to a 1/2 horse power, load contactors for larger pumps, motor starters for 3 phase applications, solenoid valves, actuated ball valves, and actuated butterfly valves.

    For more information, download the LC-91 Data Sheet.ls10dim.gif (1903 bytes)























Part Number

Wet End Material

Column Length

Base Price 5 = G

Custom Volts Price

LC-91F-0510

PVDF

To 3 Ft.

$516.00

$588.00

LC-91P-0520

PP

To 6 Ft.

$420.00

$492.00

LC-91F-0520

PVDF

To 6 Ft.

$624.00

$696.00

LC-91P-0530

PP

To 9 Ft.

$522.00

$594.00

LC-91F-0530

PVDF

To 9 Ft.

$756.00

$828.00

LC-91P-0540

PP

To 15 Ft.

$672.00

$744.00

LC-91F-0540

PVDF

To 15 Ft.

$1,020.00

$1,092.00

5 = Voltage Selection

A = 12 Vdc B = 24 Vdc

C = 48 Vdc D = 110 Vdc

E = 12 Vac    F = 24 Vac

G = 120 Vac
