LC-39 Vertical Single Point Liquid Level Controller


lc39dim.gif (1903 bytes)    The LC-39 is a single point level controller was originally designed to turn off a device, such as a heater or mixer, when the liquid level is too low.  The LC-39 contains a control head relay that is activated by a low current float switch.

    Typical applications include activating or deactivating devices such as heaters, mixers, pumps, or valves in emergency high or low level situations.  This controller can also be used to activate or deactivate panel lights, electrical horns, and panel mounted control relays.  Because it is a single point switch, this unit is not suitable for High/Low latching pump control.  See the LC-90 for details about this application.  For more information, download the LC-39 Data Sheet.



Part Number

Wet End Material

Operating Voltage

Price

LC-39P-120A

PP

120VAC

$192.00

LC-39P-012A

PP

12VAC

$216.00

LC-39P-024A

PP

24VAC

$216.00

LC-39P-012D

PP

12VDC

$216.00

LC-39P-024D

PP

24VDC

$216.00

LC-39P-048D

PP

48VDC

$216.00

LC-39F-120A

PVDF

120VAC

$216.00

LC-39F-012A

PVDF

12VAC

$252.00

LC-39F-024A

PVDF

24VAC

$252.00

LC-39F-012D

PVDF

12VDC

$252.00

LC-39F-024D

PVDF

24VDC

$252.00

LC-39F-048D

PVDF

48VDC

$252.00
